Automatic Hydraulic Drilling


Applications
Drilling, Chamfering, Reaming, Hole Milling.
Spot Facing ,Burnishing ,Countersinking, Counterboring.
For Steel or harden materials.
For aluminum or soft material.

Features
Rigid Construction
Drilling Cycle (Rapid forward-feed-dwell-rapid return).
Spindle drive through timing belt and inter chargeable pulley sets.
Hydraulic spindle feed, infinitely variable spindle speed.
Peck drilling cycle for deep hole drilling.
Specifications
Max. Drilling Capacity R-7150 R-9150 CNC-25 CNC-35
Wood Pecking Cycle ∅25mm ∅35mm ∅25mm ∅35mm
Spindle Taper yes* yes* yes* yes*
Spindle Travel MT3.NT30 MT4.NT40 ISO-30 ISO-40
Spindle Speed 3S 150mm 150mm 150mm 150mm
Throat 500.1000.1500 100.200.300 500.1000.1500 100.200.300
Column Diameter 230mm 260mm 230mm 260mm
Motor HP ∅102mm ∅115mm ∅102mm ∅115mm
2 HP 3 HP 2 HP 3 HP
