Horizontal Milling Machine
Horizontal Milling Machine
Specification
CAPACITY | Rx350 | Rx350 | |
---|---|---|---|
Max.Turning Length | mm | 500 | 500 |
Maximum Turning Diameter | mm | 300 | 350 |
Standard .Turning Diameter | mm | 200 | 230 |
Max .Turning Length (with chuck) | mm | 300 | 500 |
Admit Between Centers | mm | 350 | 550 |
Chuck Size | mm | 200 | 210 |
TRAVERSES | |||
Cross (X-Axis) Travel | mm | 175 | 175 |
Longitudinal (Z-Axis ) Travel | mm | 350 | 550 |
Rapid Feed (X & Z Axis) | m/min | 15/25 | 15/25 |
MAIN SPINDLE | |||
Spindle Motor Power | Cont/30 min | 7.5/11 kw | 7.5/11 kw |
Spindle Bore | mm | 38 | 56 |
Spindle Nose | A2-5 | A2-6 | |
Max.Bar Capacity | mm | 40 | 48 |
Spindle Speed Range | rpm | 50-4000 | 50-3500 |
Full Power Speed Range | rpm | 1000-3300 | 1000-3000 |
TAIL STOCK | |||
Quill Dia. | mm | 80 | 80 |
Quill Taper | mm | MT4 | MT4 |
Quill Stroke | mm | 100 | 100 |
Base Travel | mm | 250 | 400 |
TAIL STOCK | |||
Quill Dia. | mm | 80 | 80 |
Quill Taper | mm | MT4 | MT4 |
Quill Stroke | mm | 100 | 100 |
Base Travel | mm | 250 | 400 |
Quill Dia. | mm | 80 | 80 |
Quill Taper | mm | MT4 | MT4 |
